MAX531BCSD

low-power, voltage-output, 12-bit digital-to-analog converter, SOP14, Buffered Voltage Output, +5V, Power-On Reset

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.50~3.00

PartNumber:: MAX531BCSD

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ken(E-mail: rantle-east@vip.163.com)'s store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-16

From Other Seller

Part Number:MAX531BCSD
US $2.50 - 3.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX531BCSD is a low-power, voltage-output, 12-bit digital-to-analog converter (DAC) specified for single +5V power-supply operation. The MAX531BCSD can also be operated with ±5V supplies. The MAX531BCSD comes in 14-pin DIP and SO packages. All parts have been trimmed for offset voltage, gain, and linearity, so no further adjustment is necessary. The applications of the MAX531BCSD include Battery-Powered Test Instruments, Digital Offset and Gain Adjustment, Battery-Operated/Remote Industrial Controls, Machine and Motion Control Devices and Cellular Telephones.

Parametrics

MAX531BCSD absolute maximum ratings: (1)VDD to DGND and VDD to AGND: -0.3V, +6V; (2)VSS to DGND and VSS to AGND: -6V, +0.3V; (3)VDD to VSS: -0.3V, +12V; (4)AGND to DGND: -0.3V, +0.3V; (5)Digital Input Voltage to DGND: -0.3V, (VDD + 0.3V); (6)REFIN: (VSS - 0.3V), (VDD + 0.3V); (7)REFOUT to AGND: -0.3V, (VDD + 0.3V); (8)RFB: (VSS - 0.3V), (VDD + 0.3V); (9)BIPOFF: (VSS - 0.3V), (VDD + 0.3V); (10)VOUT: VSS, VDD; (11)Continuous Current, Any Pin: -20mA, +20mA; (12)Continuous Power Dissipation: 727mW; (13)Operating Temperature Ranges: 0 to +70℃; (14)Storage Temperature Range: -65 to +165℃; (15)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX531BCSD features: (1)Operate from Single +5V Supply; (2)Buffered Voltage Output; (3)Internal 2.048V Reference; (4)INL = ±1/2LSB (max); (5)Guaranteed Monotonic over Temperature; (6)Flexible Output Ranges: 0V to VDD; (7)Power-On Reset; (8)Serial Data Output for Daisy-Chaining.
