AD603AR

low noise, voltage-controlled amplifier, SOP8, 400 mW, ±7.5 V, -11 dB to +31 dB

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.30

PartNumber:: AD603AR

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ken(E-mail: rantle-east@vip.163.com)'s store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-17

From Other Seller

Part Number:AD603AR
US $1.00 - 1.30
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD603AR is a low noise, voltage-controlled amplifier for use in RF and IF AGC systems. It provides accurate, pin selectable gains of –11 dB to +31 dB with a bandwidth of 90 MHz or +9 dB to +51 dB with a bandwidth of 9 MHz. Any intermediate gain range may be arranged using one external resistor. The AD603AR can drive a load impedance as low as 100 W with low distortion. For a 500 W load in shunt with 5 pF, the total harmonic distortion for a ±1 V sinusoidal output at 10 MHz is typically –60 dBc. The applications of the AD603AR include: RF/IF AGC Amplifier, Video Gain Control, A/D Range Extension, Signal Measurement.

Parametrics

AD603AR absolute maximum ratings: (1)Supply Voltage ±VS: ±7.5 V; (2)Internal Voltage VINP (Pin 3): ±2 V Continuous; ±VS for 10 ms; GPOS, GNEG (Pins 1, 2): ±VS; (3)Internal Power Dissipation: 400 mW; (4)Operating Temperature Range: –40℃ to +85℃; (5)Storage Temperature Range: –65℃ to +150℃; (6)Lead Temperature Range (Soldering 60 sec): +300℃.

Features

AD603AR features: (1)Linear in dB Gain Control; (2)Pin Programmable Gain Ranges: -11 dB to +31 dB with 90 MHz Bandwidth; +9 dB to +51 dB with 9 MHz Bandwidth; (3)Any Intermediate Range, e.g., -1 dB to +41 dB with 30 MHz Bandwidth; (4)Bandwidth Independent of Variable Gain; (5)1.3 nV √Hz￣ Input Noise Spectral Density; (6)±0.5 dB Typical Gain Accuracy; (7)MIL-STD-883 Compliant and DESC Versions Available.
