TP3057WMX

"Enhanced' Serial Interface, CODEC/Filter, A-law, SOP20

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~0.90 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.80~0.90

PartNumber:: TP3057WMX

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ken(E-mail: rantle-east@vip.163.com)'s store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-04-21

From Other Seller

Part Number:TP3057WMX
US $0.80 - 0.90
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TTP3057WMX is an A-law monolithic PCM CODEC/filter utilizing the A/D and D/A conversion architecture and a serial PCM interface. The device is fabricated using Nationals advanced double-poly CMOS process (microCMOS). The encode portion of each device consists of an input gain adjust amplifier, an active RC pre-filter which eliminates very high frequency noise prior to entering a switched-capacitor band-pass filter that rejects signals below 200 Hz and above 3400 Hz. Also included are auto-zero circuitry and a companding coder which samples the filtered signal and encodes it in the companded m-law or A-law PCM format.

Parametrics

Absolute maximum ratings: (1)VCC to GNDA: 7V; (2)VBB to GNDA:-7V; (3)Voltage at any Analog Input or Output: VCC+0.3V to VBB-0.3V; (4)Voltage at any Digital Input or Output: VCC+0.3V to GNDA-0.3V; (5)operating Temperature Range: -25℃ to +125℃; (6)Storage Temperature Range: -65℃ to +150℃; (7)Lead Temperature (Soldering, 10 seconds): 300℃; (8)ESD (Human Body Model): 2000V; (9)Latch-Up Immunity =100 mA on any Pin.

Features

Features: (1)Complete CODEC and filtering system (COMBO) including: Transmit high-pass and low-pass filtering; Receive low-pass filter with sin x/x correction; Active RC noise filters; m-law or A-law compatible COder and DECoder; internal precision voltage reference; Serial I/O interface; Internal auto-zero circuitry; (2)A-law, 16-pin-TP3057; (3)Designed for D3/D4 and CCITT applications; (4)g5V operation; (5)Low operating powerDtypically 50 mW; (6)Power-down standby modeDtypically 3 mW; (7)Automatic power-down; (8)TTL or CMOS compatible digital interfaces; (9)Maximizes line interface card circuit density; (10)Dual-In-Line or surface mount packages; (11)See also AN-370, "Techniques for Designing with CODEC/Filter COMBO Circuits'.
