Product Summary

The MAX506BCWP is a CMOS, quad, 8-bit voltage output digital-to-analog converter. The device operates with a single +5V supply or dual ±5V supplies. The applications of the MAX506BCWP include minimum component count analog systems, digital offset/gain adjustment, arbitary function generators, industrial process control, automatic test equipment and programmable attenuators. The MAX506BCWP has separate input latches for each of its four DACs.

Parametrics

MAX506BCWP absolute maximum ratings: (1)VDD to AGND: -0.3V to 8V; (2)VDD to DGND: -0.3 to 6V; (3)VSS to AGND: -7 to 0.3V; (4)VSS to DGND: -7 to 0.3V; (5)VDD to VSS: -0.3 tp VDD+0.3V; (6)VREF: VSS-0.3 to VDD+0.3V; (7)VOUT: VSS to VDD; (8)contimuous power dissipation: 889mW; (9)operating temperature ranges: 0 to 70℃; (10)storage temeprature ranges: -65 to 165℃; (11)lead temperature: 300℃.

Features

MAX506BCWP features: (1)operate from single +5V supply or dual ±5V supplies; (2)output buffer amplifiers swing rail-to-rail; (3)reference input range includes both supply rails; (4)factory-calibrated for 1LSB TUE; (5)microprocessor and TTL/CMOS compatible; (6)require No external adjustments; (7)available in tiny SSOP package.

Diagrams

MAX506BCWP functional diagram
