The STV5730A-1 is a multistandard on-screen display. It is intended to be used in VCR, Satellite receiver and PAY-TV systems for CVBS or R/G/B text/graphics insertion.
Parametrics
STV5730A-1 absolute maximum ratings: (1)DVDD Digital Supply Voltage: 7 V; (2)AVDD Analog Supply Voltage: 7 V; (3)Tj Junction Temperature: 150℃.
Features
STV5730A-1 features: (1)accurate internal bandgap voltage reference; (2)line locked pll; (3)video timing generator; (4)input cvbs clamp and sync extractor; (5)vertical sync separator; (6)inputcvbs sync re-insertion; (7)inputcvbs presence detector; (8)pal/ntscchroma encoder; (9)dedicated pins for lumaand chroma external filtering; (10)gain on cvbs output for either 0db or 6db capability multistandard translucent mixed mode; (11)opaquemixed mode; (12)normal full pagemode.
