MAX233ACWP+T

+5V-Powered, Multichannel RS-232, Driver/Receiver, SOP20

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.90~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.90~1.00

PartNumber:: MAX233ACWP+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ken(E-mail: rantle-east@vip.163.com)'s store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-04-21

From Other Seller

Part Number:MAX233ACWP+T
US $0.90 - 1.00
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX233ACWP+T driver/receiver is intended for all EIA/TIA-232E and V.28/V.24 communications interfaces, particularly applications where ±12V is not available. The part is especially useful in battery-powered systems, since their low-power shutdown mode reduces power dissipation to less than 5μW. The MAX233ACWP+T uses no external components and are recommended for applications where printed circuit board space is critical.

Parametrics

Absolute maximum ratings: (1)VCC: -0.3V to +6V; (2)V+: (VCC - 0.3V) to +14V; (3)V-: +0.3V to -14V; (4)Input Voltages: TIN: -0.3V to (VCC - 0.3V); RIN (Except MAX220): ±30V; RIN (MAX220) : ±25V; TOUT (Except MAX220): ±15V; (5)Output Voltages: TOUT: .±15V; ROUT: -0.3V to (VCC + 0.3V); (6)Driver/Receiver Output Short Circuited to GND: Continuous; (7)Continuous Power Dissipation (TA = +70℃): 16-Pin Plastic DIP (derate 10.53mW/℃ above +70℃): 842mW; 18-Pin Plastic DIP (derate 11.11mW/℃ above +70℃): 889mW; 20-Pin Plastic DIP (derate 8.00mW/℃ above +70℃): 440mW; 16-Pin Narrow SO (derate 8.70mW/℃ above +70℃): 696mW; 16-Pin Wide SO (derate 9.52mW/℃ above +70℃): 762mW; 18-Pin Wide SO (derate 9.52mW/℃ above +70℃): 762mW; 20-Pin Wide SO (derate 10.00mW/℃ above +70℃): 800mW; 20-Pin SSOP (derate 8.00mW/℃ above +70℃): 640mW; 16-Pin CERDIP (derate 10.00mW/℃ above +70℃): 800mW; 18-Pin CERDIP (derate 10.53mW/℃ above +70℃): 842mW; (8)Operating Temperature Ranges: 0℃ to +70℃; (9)Storage Temperature Range: -65℃ to +160℃; (10)Lead Temperature (soldering, 10s): +300℃; (11)Soldering Temperature (reflow); (12)20 PDIP (P20M+1): +225℃; (13)All other lead(Pb)-free packages: +260℃; (14)All other packages containing lead(Pb): +240℃.

Features

Next-generation device features: (1)For Low-Voltage, Integrated ESD Applications MAX3222E/ MAX3232E/ MAX3237E/ MAX3241E/ MAX3246E: +3.0V to +5.5V, Low-Power, Up to 1Mbps, True RS-232 Transceivers Using Four 0.1uF External Capacitors (MAX3246E Available in a UCSP. Package); (2)For Low-Cost Applications: MAX221E: ±15kV ESD-Protected, +5V, 1uA,Single RS-232 Transceiver with AutoShutdown.
